3M™ 5419 tape is a translucent polyimide film insulation tape coated on one side with a silicone adhesive. It offers unique and extremely low electrostatic discharge properties for gold edge protection during wave soldering of printed circuit boards.
Electrically insulating 5419 tape is available in non-standard slit rolls, sheets and custom shapes.
For more information, please contact us.
Download: 3m-electrical-tape-5419-parafix
Adhesive | Silicone |
Carrier | Polyimide |
Colour | Amber |
Thickness (mm) | 0.07 |
Max. short temp (˚C) | 260 |
Manufacturer / SOS | 3M™ |
Elongation (%) | 60 |
Adhesion to steel (N/cm) | 2.2 |
Tensile strength (N/cm²) | 58 |
Insulation resistance (MΩ) | >1×10⁶ |
Electrostatic corrosion | No data |
