Overview for 3M™ 44T

3M™ 44T is a composite film insulating tape with a combination polyester film/polyester web coated with a rubber thermosetting adhesive. It is especially suited for applications such as building coil barriers, in which the thickness and CTI rating facilitates efficiency and effectiveness in this application.

Electrically insulating 44T tape is available in non-standard slit rolls, sheets or custom shapes.

For more information, please contact us.

Download: 3m-electrical-tape-44t-parafix

Download:

3M™ 44T

Product features for 3M™ 44T

Adhesive

Rubber

Carrier

Polyester

Colour

White

Thickness (mm)

0.42

Max. short temp (˚C)

130

Manufacturer / SOS

3M™

Elongation (%)

30

Adhesion to steel (N/cm)

8.7

Tensile strength (N/cm²)

170

Insulation resistance (MΩ)

>1×10⁶

Electrostatic corrosion

1
