  • Silicone rubber gaskets and seals custom made to your requirements

    Silicone rubber is a highly resilient material, with a long service life, due to its ability to perform in a range of extreme environments including in high temperature We supply silicone rubber gaskets and seals using the highest quality materials, including Roger’s high performance Bisco silicones, commonly used for gaskets, seals, heat shields, cushions and insulation for a variety of applications. We offer a variety of material hardness to suit your applicatino: from ultra soft grade silicone to extra hard grade silicone rubber.

    Utilising our range of converting capabilities, we can laminate silicone rubber materials with double sided adhesives and die cut the bespoke material construction into custom shapes, sizes and final presentations suited to your unique requirements. We also offer a range of silicone foams or silicone sponges.

    Silicone rubber gasket and seal can offer:

    • Performance in a wide range of temperatures
    • Good tensile strength
    • Flexibility
    • Compression set resistance
    • Inherently good electrical insulating qualities
    • Excellent resistance to environmental extremes e.g. UV, moisture, ozone and contaminants
    • Wide range of thicknesses and hardness options
  • Search silicone rubber gasket and seal products

    Browse through our full range of silicone rubbers below for more detailed information and product data sheets. If you would like to ask us a question about any of these products, simply click on “add to wish list” and the product details can be added to a contact form once you’re ready to get in touch. You can also send these details to yourself or a colleague.


    Select or remove columns to display
    Select or remove columns to display
    • Adhesive
    • Carrier
    • Colour
    • Thickness (mm)
    • Min. temp (ËšC)
    • Max. short temp (ËšC)
    • Manufacturer / SOS
    • Density (kg/m³)
    • Shore Hardness (00)
    • Compression set % max - 23ËšC
    • Compression Deflection 25% (kPa)
    • D/S or S/S
    • Breathable
    • Conformability
    • Fluid resist backing
    • Hypoallergenic
    • Sterilisation method
    • MVTR (gms/m2 /24 hrs)
    • Max width (cm)
    • Max length (m)
    Filter By
    Filter By
    • Thickness range (mm)

    • Temp. range (ËšC)

    • Density range (kg/m³)

    • Adhesive

    • Carrier

    • Colour

    • Manufacturer / SOS

    • Compression set % max - 23ËšC

    • Comp. Deflection Range 25% (kPa)

    • Shore hardness range (00)

    • D/S or S/S

    • Breathable

    • Conformability

    • Fluid resist backing

    • Hypoallergenic

    • Sterilisation method

    • MVTR (gms/m2 /24 hrs)

    • Max width (cm)

    • Max length (m)

    Reset Filters

    Any data provided relates to values typically generated when measuring these materials, and is offered as a guide to material selection. However it is not guaranteed and the user is responsible for evaluating the suitability of a product for the application it is intended for. Some test methods may vary, please refer to data sheet or call for assistance.

    Title Adhesive Breathable Carrier Colour Compression Deflection 25% (kPa) Compression set % max - 23˚C Conformability Density (kg/m³) D/S or S/S Fluid resist backing Hypoallergenic Manufacturer / SOS Max length (m) Max. short temp (˚C) Max width (cm) Min. temp (˚C) MVTR (gms/m2 /24 hrs) Shore Hardness (00) Sterilisation method Thickness (mm)
    Rogers HT-1240-0.79 Rogers HT-1240-0.79 3 None Silicone foam Red 827 No data No data Rogers -62 40 0.79
    Rogers HT-1240-1.59 Rogers HT-1240-1.59 3 None Silicone foam Red 827 No data No data Rogers -62 40 1.59
    Rogers HT-1240-2.0 Rogers HT-1240-2.0 3 None Silicone foam Red 827 No data No data Rogers -62 40 2
    Rogers HT-1240-2.38 Rogers HT-1240-2.38 3 None Silicone foam Red 827 No data No data Rogers -62 40 2.38
    Rogers HT-1240-3.18 Rogers HT-1240-3.18 3 None Silicone foam Red 827 No data No data Rogers -62 40 3.18
    Rogers HT-6240-0.25 Rogers HT-6240-0.25 3 None Silicone foam Transparent 1034 No data No data Rogers -62 40 0.25
    Rogers HT-6240-0.50 Rogers HT-6240-0.50 3 None Silicone foam Transparent 1034 No data No data Rogers -62 40 0.5
    Rogers HT-6240-0.79 Rogers HT-6240-0.79 3 None Silicone foam Transparent 1034 No data No data Rogers -62 40 0.79
    Rogers HT-6240-1.59 Rogers HT-6240-1.59 3 None Silicone foam Transparent 1034 No data No data Rogers -62 40 1.59
  • Silicone rubber in action

    Read through our case studies to find relevant, real-life examples of the powerful problem solving capabilities of our silicone rubber gaskets and seals! Browse all case studies to learn more about custom die-cut components and our tape converting capabilities.


    Airbag gasket
    Airbag gasket

    One of the largest Tier1 automotive suppliers required a gas cartridge gasket for the assembly of airbag inflators...

    Bonding silicone to plastic – medical device cushioning pad
    Bonding silicone to plastic – medical device cushioning pad

    Our customer came to us for help with sourcing an adhesive tape for bonding silicone to plastic. The application was to bond a cushioning pad to a medical device. All standard silicone tapes…

  • Custom silicone rubber gaskets and seals

    Utilising the latest converting technologies, we can customise your silicone rubber to create non-standard roll widths and lengths, or convenient and easy to handle components. Customising your material offers a number of benefits, including cost savings and enhanced product design. Whatever your needs, we have the experience and capabilities to provide a complete solution, from design and prototyping to full production and automated assembly.


    • Die-cutting
      Die-cutting
    • Slitting
      Slitting
    • Laser cutting
      Laser cutting
    • Guillotining
      Guillotining
    • Laminating
      Laminating
    • Bespoke presentations
      Bespoke presentations
    • X/Y axis plotter
      X/Y axis plotter
    • Rapid prototyping
      Rapid prototyping
    • Clean room manufacturing
      Clean room manufacturing
    • Automation solutions
      Automation solutions
    • R&D
      R&D
    • Computer Aided Design
      Computer Aided Design
    • Contract converting
      Contract converting
    • Part tolerances
      Part tolerances
