    Our single sided film tapes are available in a variety of backings, colours, thicknesses and performance characteristics. They come with rubber, acrylic or silicone adhesives for a wide range of applications, including bonding, masking, bundling, damping, splicing, reinforcing, colour coding and sealing.

    The plastic film tape backings include polyester, polypropylene, polyethylene, polyvinyl chloride (vinyl), polyimide (e.g. Kapton), polyamide (nylon), PTFE, polyvinyl alcohol (PVA), polyurethane and polyvinyl fluoride. These backing materials all affect how the underlying surface relates to the environment, for effective solutions under a variety of conditions. Click on the products tab for more information.

    Plastic film tape characteristics:

    • Conformable
    • UV, moisture and weather resistance
    • Chemical, acid and solvent resistance
    • High temperature resistance
    • Adhere to a variety of substrates including low surface energy surfaces
    • Transparent and coloured
    • Low coefficient of friction
    • Abrasion and corrosion resistance
    • Anti-stick surface, easy to clean
    • Flame retardant
    • Low static, clean room tape
    • Low electrostatic discharge
    • Impact and puncture resistance

    Our applications include:

    • High temp fineline masking
    • Surface protection
    • High tack splicing
    • Holding rivets in place during processing
    • Water contact indication
    • Lane and hazard marking
    • Noise and vibration management
    • Abrasion protection
    • Patching of canvas, rubber, leather and fabric joining
    • Colour coding
    • Performance silicone plating
    • Edge and hole reinforcing
  • Search plastic film tape

    Browse through our range of film tapes below for more detailed information and product data sheets. If you would like to ask us a question about any of these products, simply click on “add to wish list” and the product details can be added to a contact form once you’re ready to get in touch. You can also send these details to yourself or a colleague.


    Select or remove columns to display
    Select or remove columns to display
    • Adhesive
    • Carrier
    • Colour
    • Thickness (mm)
    • Min. temp (˚C)
    • Max. short temp (˚C)
    • Adhesion to steel (N/cm)
    • Tensile strength (N/cm²)
    • Max width (cm)
    • Max length (m)
    • Stock status
    • Manufacturer / SOS
    • Thermal cond. range (W/m-K)
    • Thermal conductivity (W/m-K)
    • D/S or S/S
    • Breathable
    • Conformability
    • Fluid resist backing
    • Hypoallergenic
    • Sterilisation method
    • MVTR (gms/m2 /24 hrs)
    Filter By
    Filter By
    • Thickness range (mm)

    • Adhesion to steel range (N/cm)

    • Tensile strength range (N/cm²)

    • Adhesive

    • Carrier

    • Colour

    • Max width (cm)

    • Max length (m)

    • Stock status

    • Manufacturer / SOS

    • Temp. range (˚C)

    • Thermal cond. range (W/m-K)

    • Thermal conductivity (W/m-K)

    • D/S or S/S

    • Breathable

    • Conformability

    • Fluid resist backing

    • Hypoallergenic

    • Sterilisation method

    • MVTR (gms/m2 /24 hrs)

    Any data provided relates to values typically generated when measuring these materials, and is offered as a guide to material selection. However it is not guaranteed and the user is responsible for evaluating the suitability of a product for the application it is intended for. Some test methods may vary, please refer to data sheet or call for assistance.

    Title Stock status Adhesion to steel (N/cm) Adhesive Breathable Carrier Colour Conformability D/S or S/S Fluid resist backing Hypoallergenic Manufacturer / SOS Max length (m) Max. short temp (˚C) Max width (cm) Min. temp (˚C) MVTR (gms/m2 /24 hrs) Sterilisation method Tensile strength (N/cm²) Thermal cond. range (W/m-K) Thermal conductivity (W/m-K) Thickness (mm)
    3M 5 polyester film electrical tape 3M 5 polyester film electrical tape 1 3.8 Acrylic Polyester Clear 3M™ 44 0.06
    3M™ 9948 3M™ 9948 3 2.1 Acrylic Yes PE Translucent Very high Single sided Yes Yes 3M™ 594 122 No data 400 EtO & Gamma No data 0.7
    Vancive™ MED 5576A Vancive™ MED 5576A 2 4.2 Acrylic Yes PU Transparent No data Single sided No data Yes Vancive™ No data No data No data 500 EtO & Gamma No data 0.06
    3M™ 695 3M™ 695 3 1.6 Acrylic PE Translucent yellow 3M™ -30 14 0.076
    3M™ 5421 3M™ 5421 3 3.7 Rubber PE Translucent 3M™ -34 80 0.17
    3M™ 8421 3M™ 8421 3 5.4 Rubber PET Cream 3M™ -50 75 0.06
    3M™ 2A24 3M™ 2A24 3 0.8 Acrylic Multi-polymer co-extruded Clear 3M™ No data 31 0.05
    Pregis 5504 A-UV Pregis 5504 A-UV 3 0.4 Acrylic PE Clear Pregis No data ≥20 0.056
    3M™ 850 (brown) 3M™ 850 (brown) 3 3.3 Acrylic PET Brown 3M™ -50 49 0.05
    Novacel 4336 Novacel 4336 1 90 Acrylic Polyolefin Blue Novacel No data No data 0.05
    3M™ 56 polyester film electrical tape 3M™ 56 polyester film electrical tape 1 5.5 Rubber Polyester Yellow 3M™ 44 0.06
    3M™ 9967 3M™ 9967 3 No data EVA / PE No PET Transparent Medium Single sided Yes No 3M™ No data No data EtO & Gamma 27 0.05
    Vancive™ MED 5580H Vancive™ MED 5580H 3 3.4 Hydrocolloid No data PU Transparent No data Single sided No data Yes Vancive™ No data No data No data 400 Gamma No data 0.57
    3M™ 766 3M™ 766 3 2.1 Rubber PVC Black / yellow 3M™ -16 23 0.125
    3M™ 5423 3M™ 5423 3 3.9 Rubber PE Translucent 3M™ -34 150 0.3
    3M™ 8422 3M™ 8422 3 5.4 Rubber PET Black 3M™ -50 75 0.06
    Pregis 3187C Pregis 3187C 1 1.2 Acrylic LDPE Clear Pregis No data 17 0.08
    3M™ 616-0.06 3M™ 616-0.06 3 3.9 Rubber UPVC Ruby red 3M™ No data 51 0.06
    3M™ 850 (red) 3M™ 850 (red) 3 3.3 Acrylic PET Red 3M™ -50 49 0.05
    Advance Tapes AT163 Advance Tapes AT163 2 7.4 Rubber resin PE cloth Silver Advance Tapes No data No data -50 70 0.3
    3M™ 57 polyester film electrical tape 3M™ 57 polyester film electrical tape 1 6.5 Rubber Polyester Yellow 3M™ 88 0.08
    3M™ 2475P 3M™ 2475P 3 0.32 Silicone Yes TPE film Clear High Single sided Yes Yes 3M™ 183 61 No data 600 EtO No data 0.12
    Vancive™ MED 5581H Vancive™ MED 5581H 3 3 Hydrocolloid No data PU Transparent No data Single sided No data Yes Vancive™ No data No data No data 350 Gamma No data 1.06
    3M™ 767 3M™ 767 3 2.1 Rubber PVC Red / white 3M™ -16 23 0.129
    3M™ 5425 3M™ 5425 3 5.3 Acrylic PE Translucent 3M™ -34 44 0.13
    3M™ 8429 3M™ 8429 3 7.5 Rubber PET Yellow 3M™ -50 95 0.08
    Pregis 3W26X Pregis 3W26X 3 0.28 Acrylic PE Black / white Pregis No data 17 0.08
    3M™ 616-0.07 3M™ 616-0.07 3 3.9 Rubber UPVC Ruby red 3M™ No data 51 0.07
    3M™ 850 (transparent) 3M™ 850 (transparent) 3 3.3 Acrylic PET Transparent 3M™ -50 49 0.05
    Advance Tapes AT45 Advance Tapes AT45 2 0.5 Rubber resin PVC Translucent blue Advance Tapes No data No data 0 28 0.13
    Scapa 1801 Scapa 1801 1 2.6 Silicone Polyimide Amber Scapa 30 0.07
