    Polyethylene foam, also known as PE and LDPE, is a lightweight, closed cell foam with superior performance. Polyethylene foam is strong and resilient with excellent energy absorption and acoustic properties. Common applications include shock absorbing, vibration damping, thermal insulation, gasketing and sealing across a range of industries.

    Crosslinked polyethylene foam is also available, which offers enhanced performance due to the stronger cell structure. Utilising our range of converting capabilities, we can laminate closed cell polyethylene foam with double sided adhesives and convert the bespoke material construction into custom shapes, sizes and final presentations suited to your unique requirements.

    Polyethylene foam characteristics:

    • Closed cell
    • Excellent chemical resistance
    • Resistant to chemicals and grease
    • Excellent resistance to environmental extremes e.g. UV, ozone and moisture
    • Available in a range of thicknesses and colours
    • Lightweight, flexible and durable
    • Low water absorption and vapour transmission
    • Performs in high and low temperatures
  • Search Polyethylene foam

    Browse through our full range of polyethylene foams below for more detailed information and product data sheets. If you would like to ask us a question about any of these products, simply click on “add to wish list” and the product details can be added to a contact form once you’re ready to get in touch. You can also send these details to yourself or a colleague.


    Select or remove columns to display
    Select or remove columns to display
    Select or remove columns to display
    • Adhesive
    • Carrier
    • Colour
    • Thickness (mm)
    • Min. temp (ËšC)
    • Max. short temp (ËšC)
    • Stock status
    • Manufacturer / SOS
    • Density (kg/m³)
    • Shore Hardness (00)
    • Compression set % max - 23ËšC
    • Compression Deflection 25% (kPa)
    • D/S or S/S
    • Breathable
    • Conformability
    • Fluid resist backing
    • Hypoallergenic
    • Sterilisation method
    • MVTR (gms/m2 /24 hrs)
    • Max width (cm)
    • Max length (m)
    Filter By
    Filter By
    Filter By
    • Thickness range (mm)

    • Temp. range (ËšC)

    • Density range (kg/m³)

    • Adhesive

    • Carrier

    • Colour

    • Stock status

    • Manufacturer / SOS

    • Compression set % max - 23ËšC

    • Comp. Deflection Range 25% (kPa)

    • Shore hardness range (00)

    • D/S or S/S

    • Breathable

    • Conformability

    • Fluid resist backing

    • Hypoallergenic

    • Sterilisation method

    • MVTR (gms/m2 /24 hrs)

    • Max width (cm)

    • Max length (m)

    Reset Filters

    Any data provided relates to values typically generated when measuring these materials, and is offered as a guide to material selection. However it is not guaranteed and the user is responsible for evaluating the suitability of a product for the application it is intended for. Some test methods may vary, please refer to data sheet or call for assistance.

    Title Stock status Adhesive Breathable Carrier Colour Compression Deflection 25% (kPa) Compression set % max - 23˚C Conformability Density (kg/m³) D/S or S/S Fluid resist backing Hypoallergenic Manufacturer / SOS Max length (m) Max. short temp (˚C) Max width (cm) Min. temp (˚C) MVTR (gms/m2 /24 hrs) Shore Hardness (00) Sterilisation method Thickness (mm)
    3Mâ„¢ 9536 3Mâ„¢ 9536 2 Rubber PE foam White No data No data 55 3Mâ„¢ -40 No data 1.02
    Vanciveâ„¢ MED 5676A Vanciveâ„¢ MED 5676A 2 Acrylic No data PE foam White No data No data No data No data Single sided No data No Vanciveâ„¢ No data No data No data No data No data EtO & Gamma 1.55
    3Mâ„¢ 9546 3Mâ„¢ 9546 2 Acrylic PE foam White No data No data 67 3Mâ„¢ -40 No data 1.15
    Vanciveâ„¢ MED 5685A Vanciveâ„¢ MED 5685A 2 Acrylic No data PE foam White No data No data No data No data Single sided No data No Vanciveâ„¢ No data No data No data No data No data EtO & Gamma 1.05
    tesa 62934 tesa 62934 3 Acrylic PE foam Black No data No data No data tesa® -30 No data 0.8
    Vanciveâ„¢ MED 5696R Vanciveâ„¢ MED 5696R 2 Rubber No data PE foam White No data No data No data No data Single sided No data No Vanciveâ„¢ No data No data No data No data No data EtO & Gamma 1.05
    tesa® 62936 tesa® 62936 2 Acrylic PE foam White No data No data No data tesa® -30 No data 1.6
    Scapa 3829-10.0 Scapa 3829-10.0 2 Rubber PE foam Black 2.5 <10 No data Scapa -30 55 10
    3Mâ„¢ 4492B 3Mâ„¢ 4492B 2 Acrylic PE foam Black No data No data 95 3Mâ„¢ -40 No data 0.8
    Scapa 3829-3.0 Scapa 3829-3.0 2 Rubber PE foam Black 2.5 <10 No data Scapa -30 55 3
    3Mâ„¢ 4492W 3Mâ„¢ 4492W 2 Acrylic PE foam White No data No data 95 3Mâ„¢ -40 No data 0.8
    Scapa 3829-4.0 Scapa 3829-4.0 2 Rubber PE foam Black 2.5 <10 No data Scapa -30 55 4
    3Mâ„¢ 4496B 3Mâ„¢ 4496B 2 Acrylic PE foam Black No data No data 65 3Mâ„¢ -40 No data 1.6
    Scapa 3829-5.0 Scapa 3829-5.0 3 Rubber PE foam Black 2.5 <10 No data Scapa -30 55 5
    3Mâ„¢ 4496W 3Mâ„¢ 4496W 2 Acrylic PE foam White No data No data 65 3Mâ„¢ -40 No data 1.6
    R516-1.0 R516-1.0 1 Hot melt Polyether foam Grey No data 12 27-29 Parafix -20 135 - 165 1
    tesa® 62932 (black) tesa® 62932 (black) 2 Acrylic PE foam Black No data No data No data tesa® -30 No data 0.5
    R516-10.0 R516-10.0 1 Hot melt Polyether foam Grey No data 12 27-29 Parafix -20 135 - 165 10
    tesa® 62932 (white) tesa® 62932 (white) 2 Acrylic PE foam White No data No data No data tesa® -30 No data 0.5
    R516-2.0 R516-2.0 1 Hot melt Polyether foam Grey No data 12 27-29 Parafix -20 135 - 165 2
    3Mâ„¢ 1772 3Mâ„¢ 1772 3 Acrylic No PE foam White No data No data Low No data Single sided Yes Yes 3Mâ„¢ 73 122 No data No data No data EtO & Gamma 1.7
    R516-3.0 R516-3.0 1 Hot melt Polyether foam Grey No data 12 27-29 Parafix -20 135 - 165 3
    Scapa 5469 Scapa 5469 2 Acrylic PE foam Black No data No data No data Scapa -40 No data 1
    3Mâ„¢ 1773 3Mâ„¢ 1773 3 Acrylic No PE foam White No data No data Medium No data Single sided Yes Yes 3Mâ„¢ 132 122 No data No data No data EtO & Gamma 0.9
    R516-5.0 R516-5.0 1 Hot melt Polyether foam Grey No data 12 27-29 Parafix -20 135 - 165 5
    Scapa 5574 Scapa 5574 2 Rubber PE foam White No data No data No data Scapa -40 No data 0.8
    3Mâ„¢ 9776 3Mâ„¢ 9776 1 Acrylic No PE foam Tan No data No data Medium No data Single sided Yes Yes 3Mâ„¢ 132 122 No data No data No data EtO & Gamma 0.9
    R516-6.0 R516-6.0 1 Hot melt Polyether foam Grey No data 12 27-29 Parafix -20 135 - 165 6
    Scapa 5589 Scapa 5589 2 Acrylic PE foam Black No data No data No data Scapa -40 No data 0.8
    3Mâ„¢ 1774T 3Mâ„¢ 1774T 3 Acrylic No PE foam Tan No data No data High No data Single sided Yes Yes 3Mâ„¢ 264 122 No data No data No data EtO & Gamma 0.6
    R516-8.0 R516-8.0 1 Hot melt Polyether foam Grey No data 12 27-29 Parafix -20 135 - 165 8
    3Mâ„¢ 9528 3Mâ„¢ 9528 2 Rubber PE foam White No data No data 70 3Mâ„¢ -30 No data 0.8
    3Mâ„¢ 1774W 3Mâ„¢ 1774W 3 Acrylic No PE foam White No data No data High No data Single sided Yes Yes 3Mâ„¢ 264 122 No data No data No data EtO & Gamma 0.6
    Vanciveâ„¢ MED 5688A Vanciveâ„¢ MED 5688A 3 Acrylic No data PE foam White No data No data Very high No data Single sided No No Vanciveâ„¢ 365 152.4 No data No data No data EtO & Gamma 0.8
    3Mâ„¢ 9529 3Mâ„¢ 9529 2 Rubber PE foam White No data No data 70 3Mâ„¢ -30 No data 1.5
    Vanciveâ„¢ MED 5674U Vanciveâ„¢ MED 5674U 2 Acrylic No data PE foam White No data No data No data No data Single sided No data No Vanciveâ„¢ No data No data No data No data No data EtO & Gamma 1.07
    Vanciveâ„¢ MED 5684U Vanciveâ„¢ MED 5684U 3 Acrylic No data PE foam Pink No data No data Very high No data Single sided No No Vanciveâ„¢ 365 152.4 No data No data No data EtO & Gamma 1.07
  • Polyethylene foam in action

    Read through our case studies to find relevant, real-life examples of the powerful problem solving capabilities of our Polyethylene foam! Browse all case studies to learn more about custom die-cut components and our tape converting capabilities.


  • Customising your Polyethylene foam

    Utilising the latest converting technologies, we can customise your Polyethylene foam to create non-standard roll widths and lengths, or convenient and easy to handle components. Customising your material offers a number of benefits, including cost savings and enhanced product design. Whatever your needs, we have the experience and capabilities to provide a complete solution, from design and prototyping to full production and automated assembly.
