Single sided foil tape consists of an adhesive coated onto an aluminium foil, copper foil or lead foil backing. They are available in a range of thicknesses and performance levels for both general purpose and high performance applications.
Copper and aluminium foil tapes are commonly used in construction, industrial, electronics, automotive, aerospace and HVAC markets. They offer reliable performance for a range of applications such as masking, splicing, damping, shielding, insulating, sealing, reflecting and fixing.
Our single coated foil tapes bond to a variety of different surfaces including wood, metal and plastic and are suitable for internal or external use. We have an extensive range of foil tapes from world leading manufacturers; click on the products tab to learn more.
Aluminium and copper foil tape characteristics:
Our applications include:
Browse through our range of single sided foil tapes below for more detailed information and product data sheets. If you would like to ask us a question about any of these products, simply click on “add to wish list” and the product details can be added to a contact form once you’re ready to get in touch. You can also send these details to yourself or a colleague.Â
Thickness range (mm)
Adhesion to steel range (N/cm)
Tensile strength range (N/cm²)
Adhesive
Carrier
Colour
Max width (cm)
Max length (m)
Stock status
Manufacturer / SOS
Temp. range (ËšC)
Thermal cond. range (W/m-K)
Thermal conductivity (W/m-K)
D/S or S/S
Breathable
Conformability
Fluid resist backing
Hypoallergenic
Sterilisation method
MVTR (gms/m2 /24 hrs)
Any data provided relates to values typically generated when measuring these materials, and is offered as a guide to material selection. However it is not guaranteed and the user is responsible for evaluating the suitability of a product for the application it is intended for. Some test methods may vary, please refer to data sheet or call for assistance.
Title | Stock status | Adhesion to steel (N/cm) | Adhesive | Breathable | Carrier | Colour | Conformability | D/S or S/S | Fluid resist backing | Hypoallergenic | Manufacturer / SOS | Max length (m) | Max. short temp (˚C) | Max width (cm) | Min. temp (˚C) | MVTR (gms/m2 /24 hrs) | Sterilisation method | Tensile strength (N/cm²) | Thermal cond. range (W/m-K) | Thermal conductivity (W/m-K) | Thickness (mm) | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3Mâ„¢ 9792R | 3 | 3.9 | Acrylic | No | Aluminium foil | Silver | High | Single sided | Yes | No | 3Mâ„¢ | 457 | 106.7 | -70 | No data | EtO & Gamma | No data | 0.07 | ||||
3M 421 | 3 | 3.4 | Rubber | Lead foil | Dark silver | 3Mâ„¢ | -51 | 26 | 0.16 | |||||||||||||
3Mâ„¢ 363L | 2 | 5.7 | Silicone | Aluminium / glass | Shiny silver | 3Mâ„¢ | -54 | 236 | 0.19 | |||||||||||||
3Mâ„¢ 9793R | 3 | 2.8 | Acrylic | No | PP | Transparent | Medium | Single sided | Yes | No | 3Mâ„¢ | 457 | 122 | -70 | No data | EtO | No data | 0.08 | ||||
3Mâ„¢ 425 | 2 | 5.1 | Acrylic | Soft aluminium | Shiny silver | 3Mâ„¢ | -54 | 49 | 0.12 | |||||||||||||
Advance Tapes AT500 | 2 | 3.8 | Acrylic | Aluminium foil | Silver | Advance Tapes | No data | No data | -20 | 22 | 0.08 | |||||||||||
3Mâ„¢ 9795R | 1 | 3.9 | Silicone | No | PP | Transparent | Medium | Single sided | Yes | No | 3Mâ„¢ | 675 | 122 | -70 | No data | No data | No data | 0.1 | ||||
3Mâ„¢ 431 | 3 | 4.5 | Acrylic | Soft aluminium | Shiny silver | 3Mâ„¢ | -54 | 34 | 0.08 | |||||||||||||
Advance Tapes AT502 | 2 | 3.6 | Acrylic | Aluminium foil | Silver | Advance Tapes | No data | No data | -20 | 12 | 0.07 | |||||||||||
3Mâ„¢ 1170 | 1 | 3.8 | Acrylic | Aluminium foil | Silver | 3Mâ„¢ | -40 | 35 | 0.08 | |||||||||||||
3Mâ„¢ 433 | 3 | 4.4 | Silicone | Aluminium foil | Shiny silver | 3Mâ„¢ | -54 | 35 | 0.09 | |||||||||||||
3Mâ„¢ 1181 | 1 | 3.8 | Acrylic | Copper foil | Copper | 3Mâ„¢ | No data | 44 | 0.07 | |||||||||||||
3Mâ„¢ 434 | 3 | 7.1 | Synthetic rubber | Soft aluminium | Silver | 3Mâ„¢ | -55 | 88 | 0.19 | |||||||||||||
3Mâ„¢ 1182 | 3 | 3.8 | Acrylic | Copper foil | Copper | 3Mâ„¢ | No data | 44 | 0.09 | |||||||||||||
3Mâ„¢ 435 | 3 | 7.1 | Synthetic rubber | Soft aluminium | Silver | 3Mâ„¢ | -55 | 88 | 0.34 | |||||||||||||
3Mâ„¢ 1245 | 1 | 3.8 | Acrylic | Copper foil | Copper | 3Mâ„¢ | No data | 44 | 0.1 | |||||||||||||
3Mâ„¢ 436 | 3 | 7.1 | Synthetic rubber | Soft aluminium | Silver | 3Mâ„¢ | -55 | 88 | 0.45 | |||||||||||||
3Mâ„¢ 1345 | 3 | 3.8 | Acrylic | Tin-plated copper foil | Silver | 3Mâ„¢ | -40 | 44 | 0.1 | |||||||||||||
3Mâ„¢ 1436 | 3 | 12 | Rubber | Soft aluminium | Silver | 3Mâ„¢ | -25 | 18 | 0.075 | |||||||||||||
3Mâ„¢ 1115B | 3 | 5.6 | Acrylic | Aluminium foil | Silver | 3Mâ„¢ | -40 | 70 | 0.15 | |||||||||||||
3Mâ„¢ 1449 | 3 | 4 | Acrylic | Soft aluminium | Shiny silver | 3Mâ„¢ | -32 | 33 | 0.07 | |||||||||||||
3Mâ„¢ AL25BT | 3 | 3.4 | Acrylic | Aluminium foil | Silver | 3Mâ„¢ | No data | No data | 0.06 | |||||||||||||
3Mâ„¢ 1450 | 3 | 12.5 | Rubber | Soft aluminium | Shiny silver | 3Mâ„¢ | -40 | 33 | 0.08 | |||||||||||||
3Mâ„¢ AL36FR | 3 | 2.2 | Acrylic | Polyester / aluminium foil | Black | 3Mâ„¢ | No data | No data | 0.06 | |||||||||||||
3Mâ„¢ 2552 | 3 | 7.2 | Acrylic | Soft aluminium | Silver | 3Mâ„¢ | -32 | 220 | 0.38 | |||||||||||||
3Mâ„¢ AL36NC | 3 | 500 | Acrylic | Polyester / aluminium foil | Silver | 3Mâ„¢ | No data | 6.5 | 0.07 | |||||||||||||
3Mâ„¢ 3311 | 3 | 9.8 | Rubber | Aluminium foil | Silver | 3Mâ„¢ | -23 | 30 | 0.09 | |||||||||||||
3Mâ„¢ AL39UL | 3 | No data | Acrylic | Polyester / aluminium foil | Black | 3Mâ„¢ | No data | No data | 0.06 | |||||||||||||
3Mâ„¢ 3326 | 3 | 7.7 | Acrylic | Aluminium foil | Silver | 3Mâ„¢ | -29 | 44 | 0.11 | |||||||||||||
3Mâ„¢ CU35C | 3 | 3.5 | Acrylic | Copper foil | Copper | 3Mâ„¢ | No data | No data | 0.07 | |||||||||||||
3Mâ„¢ 8561 | 3 | 4.5 | Acrylic | PU | Transparent | 3Mâ„¢ | -51 | 131 | 0.36 | |||||||||||||
3Mâ„¢ 363 | 2 | 5.7 | Silicone | Aluminium / glass | Shiny silver | 3Mâ„¢ | -54 | 236 | 0.2 | |||||||||||||
Premier Coatings CP18-100 | 1 | 5.8 | Acrylic | Aluminium foil | Silver | Premier Coatings | -5 | No data | 0.1 | |||||||||||||
3Mâ„¢ 9967 | 3 | No data | EVA / PE | No | PET | Transparent | Medium | Single sided | Yes | No | 3Mâ„¢ | No data | No data | EtO & Gamma | 27 | 0.05 | ||||||
3Mâ„¢ 420 | 3 | 4.9 | Rubber | Lead foil | Dark silver | 3Mâ„¢ | -51 | 35 | 0.17 | |||||||||||||
Premier Coatings CP18-38 | 1 | 5.8 | Acrylic | Aluminium foil | Silver | Premier Coatings | -5 | No data | 0.04 |
Read through our case studies to find relevant, real-life examples of the powerful problem solving capabilities of a roll of foil tape! Browse all case studies to learn more about custom die-cut components and our tape converting capabilities.
Utilising the latest converting technologies, we can customise your foil tape to create non-standard roll widths and lengths, or convenient and easy to handle components. Customising your tape offers a number of benefits, including cost savings and enhanced product design. Whatever your needs, we have the experience and capabilities to provide a complete solution, from design and prototyping to full production and automated assembly.
To learn more about our single sided foil tapes and their uses, browse through our range of interesting and relevant videos, news and other media.
View a range of automated assembly solutions using AccuPlace automated equipment. Â
Learn more about AccuPlace solutions here.Â
