Neoprene Foam

  • Overview
  • Products
  • Case Studies
  • Capabilities
  • Media

  • About neoprene foam

    Neoprene foam is a closed cell foam, that is impermeable to air and water, providing superior sealing against ingress of liquids, including oils and chemicals. Neoprene foam tape is commonly used in applications such as sealing and gasketing of electronics, especially those within automotive devices. Other applications include those requiring cushioning and vibration damping.

    Utilising our range of converting capabilities, we can laminate closed cell neoprene foam with double sided adhesives and convert the bespoke material construction into custom shapes, sizes and final presentations suited to your unique requirements.

    Closed cell neoprene characteristics:

    • Good UV, ozone and oxidation resilience
    • Flame retardant
    • Resistant to oils and chemicals
    • Flexible and durable
    • Available in a range of colours
    • Excellent ageing properties
    • Resistant to extreme high and low temperatures
    • Available in a range of thicknesses

  • Search neoprene foam

    Browse through our range of neoprene foams below for more detailed information and product data sheets. If you would like to ask us a question about any of these products, simply click on “add to wish list” and the product details can be added to a contact form once you’re ready to get in touch. You can also send these details to yourself or a colleague.

    Select or remove columns to display
    Select or remove columns to display
    Select or remove columns to display
    • Adhesive
    • Carrier
    • Colour
    • Thickness (mm)
    • Min. temp (ËšC)
    • Max. short temp (ËšC)
    • Stock status
    • Manufacturer / SOS
    • Density (kg/m³)
    • Shore Hardness (00)
    • Compression set % max - 23ËšC
    • Compression Deflection 25% (kPa)
    • D/S or S/S
    • Breathable
    • Conformability
    • Fluid resist backing
    • Hypoallergenic
    • Sterilisation method
    • MVTR (gms/m2 /24 hrs)
    • Max width (cm)
    • Max length (m)
    Filter By
    Filter By
    Filter By

    • Thickness range (mm)

    • Temp. range (ËšC)

    • Density range (kg/m³)

    • Adhesive

    • Carrier

    • Colour

    • Stock status

    • Manufacturer / SOS

    • Compression set % max - 23ËšC

    • Comp. Deflection Range 25% (kPa)

    • Shore hardness range (00)

    • D/S or S/S

    • Breathable

    • Conformability

    • Fluid resist backing

    • Hypoallergenic

    • Sterilisation method

    • MVTR (gms/m2 /24 hrs)

    • Max width (cm)

    • Max length (m)

    Reset Filters

    Any data provided relates to values typically generated when measuring these materials, and is offered as a guide to material selection. However it is not guaranteed and the user is responsible for evaluating the suitability of a product for the application it is intended for. Some test methods may vary, please refer to data sheet or call for assistance.

    Title Stock status Adhesive Breathable Carrier Colour Compression Deflection 25% (kPa) Compression set % max - 23˚C Conformability Density (kg/m³) D/S or S/S Fluid resist backing Hypoallergenic Manufacturer / SOS Max length (m) Max. short temp (˚C) Max width (cm) Min. temp (˚C) MVTR (gms/m2 /24 hrs) Shore Hardness (00) Sterilisation method Thickness (mm)
    R210 R210 3 None Neoprene / EPDM Black 48 No data 96 Parafix -40 50 1
    R252/8 R252/8 1 None Expanded neoprene EPDM Black 44 35 110 Parafix -40 No data 2
    5041 5041 1 Synthetic rubber Expanded neoprene EPDM Black 35-63 No data 112 Parafix -56.6 No data 2
    5042 5042 1 Synthetic rubber Expanded neoprene EPDM Black 35-63 No data 112 Parafix -56.6 No data 3
    5043 5043 1 Synthetic rubber Expanded neoprene EPDM Black 35-63 No data 112 Parafix -56.6 No data 4
    5040 5040 1 Synthetic rubber Expanded neoprene EPDM Black 35-63 No data 112 Parafix -56.6 No data 1

  • Neoprene foam in action

    Read through our case studies to find relevant, real-life examples of the powerful problem solving capabilities of our neoprene foam! Browse all case studies to learn more about custom die-cut components and our tape converting capabilities.

    Development of o-ring substitute in Antenna Casing
    Development of o-ring substitute in Antenna Casing
    Joining and sealing solution for antenna casing in external environment...

  • Customising your material

    Utilising the latest converting technologies, we can customise your neoprene foam to create non-standard roll widths and lengths, or convenient and easy to handle components. Customising your material offers a number of benefits, including cost savings and enhanced product design. Whatever your needs, we have the experience and capabilities to provide a complete solution, from design and prototyping to full production and automated assembly.

    • Die-cutting
      Die-cutting
      We use a range of die-cutting equipment to create your bespoke adhesive components...
    • Slitting
      Slitting
      The cutting of large rolls of material to non-standard widths and lengths...
    • Laser cutting
      Laser cutting
      For cutting small, complicated geometries or features...
    • Guillotining
      Guillotining
      For laminating and sheeting to custom sizes...
    • Laminating
      Laminating
      Laminate materials fully or in selective areas, for a bespoke material construction...
    • Bespoke presentations
      Bespoke presentations
      For an efficient design that aids quick and accurate assembly...
    • X/Y axis plotter
      X/Y axis plotter
      For producing prototypes and small batch runs...
    • Rapid prototyping
      Rapid prototyping
      To test and demonstrate products in the early stages of design...
    • Clean room manufacturing
      Clean room manufacturing
      For a controlled manufacturing environment...
    • Automation solutions
      Automation solutions
      Reduce costs and enhance quality with automated pick and place equipment...
    • R&D
      R&D
      Assistance in developing the most effective part in form, function and presentation...
    • Computer Aided Design
      Computer Aided Design
      For accurate and optimum component design...
    • Contract converting
      Contract converting
      We can customise your material into bespoke shapes and combine it with complimentary products...
    • Part tolerances
      Part tolerances
      View our part tolerance standard values and talk to us about your requirements
