  • About adhesive transfer tape

    An adhesive transfer tape is a pressure sensitive adhesive with no carrier, directly coated onto a release liner. These tapes very quickly bond two surfaces and can be easily applied by hand, with a dispenser or using automated pick and place technology. They are designed to increase manufacturing efficiency by replacing traditional bonding and fastening materials, offering a reliable bonding solution.

    Adhesive transfer tapes are especially suitable where a thin and invisible bond is required and are ideal for bonding lightweight materials like paper, cloth or plastic. They are available in a variety of thicknesses and adhesive formulations and will attach a wide range of similar and dissimilar materials. Repositionable transfer tapes are also available and can be removed and reused numerous times without leaving any adhesive residue.

    We can easily combine transfer tapes with other materials,  such as laminating to foams. They are easily die-cut into convenient shapes and sizes; offering a variety of options to meet your individual needs.

    We offer an extensive range of transfer tapes from World leading manufacturers. Click on the products tab for more information.

  • Search adhesive transfer tapes

    Browse through our range of adhesive transfer tapes below for more detailed information and product data sheets. If you would like to ask us a question about any of these products, simply click on “add to wish list” and the product details can be added to a contact form once you’re ready to get in touch. You can also send these details to yourself or a colleague.


    Select or remove columns to display
    Select or remove columns to display
    • Adhesive
    • Carrier
    • Colour
    • Thickness (mm)
    • Min. temp (˚C)
    • Max. long temp (˚C)
    • Max. short temp (˚C)
    • Chem resist
    • UV resist
    • Bond to metal
    • Bond to HSE plastic
    • Bond to LSE plastic
    • Bond to foam, felt, mesh
    • Max width (cm)
    • Max length (m)
    • Manufacturer / SOS
    • D/S or S/S
    • Sterilisation method
    Filter By
    Filter By

    • Thickness range (mm)

    • Temp. range (˚C)

    • Adhesive

    • Carrier

    • Colour

    • Chem resist

    • UV resist

    • Bond to metal

    • Bond to HSE plastic

    • Bond to LSE plastic

    • Bond to foam, felt, mesh

    • Max width (cm)

    • Max length (m)

    • Manufacturer / SOS

    • D/S or S/S

    • Sterilisation method

    Reset Filters

    Any data provided relates to values typically generated when measuring these materials, and is offered as a guide to material selection. However it is not guaranteed and the user is responsible for evaluating the suitability of a product for the application it is intended for. Some test methods may vary, please refer to data sheet or call for assistance.

    Title Adhesive Bond to foam, felt, mesh Bond to HSE plastic Bond to LSE plastic Bond to metal Carrier Chem resist Colour D/S or S/S Manufacturer / SOS Max length (m) Max. long temp (˚C) Max. short temp (˚C) Max width (cm) Min. temp (˚C) Sterilisation method Thickness (mm) UV resist
    3M™ 9882 3M™ 9882 3 Acrylic Filled acrylic polymer 3 Grey 3M™ No data -35 0.05 4
    Vancive™ MED 2190H Vancive™ MED 2190H 3 Hydrocolloid None No data Transparent Double sided Vancive™ No data No data No data No data Gamma 0.51 No data
    Vancive™ MED 2191H Vancive™ MED 2191H 3 Hydrocolloid None No data Transparent Double sided Vancive™ No data No data No data No data Gamma 1 No data
    Vancive™ MED 2195H Vancive™ MED 2195H 3 Hydrocolloid None No data Transparent Double sided Vancive™ No data No data No data No data Gamma 0.51 No data
    Vancive™ MED 2198H Vancive™ MED 2198H 3 Hydrocolloid None No data Transparent Vancive™ No data No data 0.41 No data
    3M™ 9703 3M™ 9703 2 Acrylic No data 2 2 3 None 3 Clear Double sided 3M™ No data -40 0.05 4
    Laird Tgon™ 805 Laird Tgon™ 805 3 None Flexible graphite Pewter Laird -240 0.13
    3M™ 8805 3M™ 8805 1 Acrylic Filled acrylic polymer No data White Double sided 3M™ No data No data 0.13 No data
    3M™ 9885 3M™ 9885 3 Acrylic Filled acrylic polymer 3 Grey Double sided 3M™ No data -35 0.13 4
    3M™ 5516 3M™ 5516 1 None Filled silicone polymer‎ Grey Double sided 3M™ No data 1
    3M™ 8810 3M™ 8810 1 Acrylic Filled acrylic polymer No data White 3M™ No data No data 0.25 No data
    3M™ 8815 3M™ 8815 2 Acrylic Filled acrylic polymer No data White 3M™ No data No data 0.38 No data
    Vancive™ MED 2171H Vancive™ MED 2171H 3 Hydrocolloid None No data Transparent Double sided Vancive™ No data No data No data No data Gamma 0.3 No data
    3M™ 98010LVC 3M™ 98010LVC 2 Acrylic 4 4 4 4 None 3 Clear Double sided 3M™ 121 -30 0.1 3
    3M™ 99015LVC 3M™ 99015LVC 2 Acrylic 4 4 4 4 Tissue 3 Clear Double sided 3M™ 182 -30 0.15 3
    3M™ 1524A 3M™ 1524A 3 Acrylic None Transparent Double sided 3M™ 366 122 No data EtO, Gamma & Steam 0.06
    Vancive™ MED 21010H Vancive™ MED 21010H 3 Hydrocolloid None No data Double sided Vancive™ 365 152.4 No data Gamma 0.6
    Vancive™ MED 21009H Vancive™ MED 21009H 2 Hydrocolloid None No data Double sided Vancive™ 365 152.4 No data Gamma 0.3
    Vancive™ MED 2159H Vancive™ MED 2159H 3 Hydrocolloid None No data Transparent Double sided Vancive™ No data 152.4 No data Gamma 1.2 No data
    Vancive™ MED 2196H Vancive™ MED 2196H 3 Hydrocolloid None No data Transparent Double sided Vancive™ No data 152.4 No data Gamma 2.4 No data
    Avery Dennison™ MED 2120U Avery Dennison™ MED 2120U 3 Acrylic None No data Transparent Double sided Avery Dennison Medical No data 152.4 No data EtO & Gamma 0.06 No data
    Avery Dennison™ MED 2121U Avery Dennison™ MED 2121U 3 Acrylic None No data Transparent Double sided Avery Dennison Medical No data 152.4 No data EtO & Gamma 0.04 No data
    Avery Dennison™ MED 2123R Avery Dennison™ MED 2123R 3 Synthetic rubber None No data Transparent Double sided Avery Dennison Medical No data 152.4 No data EtO & Gamma 0.04 No data
    Solventum™ (formerly 3M™) 4075 Solventum™ (formerly 3M™) 4075 Acrylic None Transparent Double sided 3M™ No data EtO 0.07
    3M™ 9713 3M™ 9713 3 Acrylic No data No data No data No data None No data No data Double sided 3M™ 70 No data 0.09 No data
    3M™ 927 3M™ 927 1 Acrylic 3 5 4 5 None 3 Clear Double sided 3M™ 82 -30 0.05 4
    3M™ 950 3M™ 950 1 Acrylic 5 5 5 4 None 3 Clear Double sided 3M™ 82 -30 0.127 4
    3M™ 966 3M™ 966 2 Acrylic 1 4 1 5 None 5 Clear Double sided 3M™ 149 -40 0.06 5
    3M™ 8171 3M™ 8171 3 Acrylic 2 5 2 5 None 5 Optically clear Double sided 3M™ 85 -40 0.025 5
    3M™ 8172 3M™ 8172 3 Acrylic 2 5 2 5 None 5 Optically clear Double sided 3M™ 85 -40 0.05 5
    3M™ F-9465PC 3M™ F-9465PC 2 Acrylic 2 4 1 5 None 2 Clear Double sided 3M™ 74 -30 0.13 4
    3M™ 9482PC 3M™ 9482PC 1 Acrylic 5 5 5 5 None 4 Clear Double sided 3M™ 150 -40 0.05 4
    3M™ 9485 3M™ 9485 1 Acrylic 5 5 5 5 None 4 Clear Double sided 3M™ 149 -40 0.127 4
    3M™ 9605 3M™ 9605 1 Acrylic 3 4 3 4 None 3 Clear Double sided 3M™ 120 -30 0.05 4
    3M™ 9626 3M™ 9626 2 Acrylic 5 5 5 5 None 4 Clear Double sided 3M™ 93 -40 0.05 4
    3M™ 9627 3M™ 9627 2 Acrylic 5 5 5 5 None 4 Clear Double sided 3M™ 93 -40 0.13 4
    3M™ 465 3M™ 465 3 Acrylic 2 3 3 3 None 3 Clear Double sided 3M™ 82 -30 0.05 4
    3M 467MP 3M 467MP 1 Acrylic 1 5 1 5 None 4 Clear Double sided 3M™ 149 -30 0.06 5
    3M™ 468MP 3M™ 468MP 1 Acrylic 1 5 1 5 None 4 Clear Double sided 3M™ 149 -30 0.13 5
    3M™ 920XL 3M™ 920XL 2 Acrylic 3 4 3 5 None 3 Clear Double sided 3M™ 80 -30 0.025 4
    3M™ 9471LE 3M™ 9471LE 1 Acrylic 1 5 5 5 None 4 Clear Double sided 3M™ 93 -40 0.058 4
    3M™ 9472LE 3M™ 9472LE 2 Acrylic 1 5 5 5 None 4 Clear Double sided 3M™ 93 -40 0.132 4
    3M™ F9460PC VHB™ 3M™ F9460PC VHB™ 1 Acrylic 1 4 1 5 None 5 Clear Double sided 3M™ 149 -30 0.05 5
    3M™ F9469PC VHB™ 3M™ F9469PC VHB™ 1 Acrylic 1 4 1 5 None 5 Clear Double sided 3M™ 149 -30 0.13 5
    3M™ F9473PC VHB™ 3M™ F9473PC VHB™ 1 Acrylic 1 4 1 5 None 5 Clear Double sided 3M™ 149 -30 0.26 5
    Solventum™ (formerly 3M™) 1504XL Solventum™ (formerly 3M™) 1504XL 3 Synthetic rubber None No data Translucent Double sided 3M™ 549 No data 15 No data EtO & Gamma 0.11 No data
    Adhesives Research 7396 Adhesives Research 7396 3 Acrylic None Translucent Double sided Adhesives Research No data Gamma 0.12
    Adhesives Research 8026 Adhesives Research 8026 3 Silicone None No data No data Double sided Adhesives Research No data No data No data -73 No data 0.025 No data

  • Adhesive transfer tape in action

    Read through our case studies to find relevant, real-life examples of the powerful problem solving capabilities of a roll of tape! Browse all case studies to learn more about custom die-cut components and our tape converting capabilities.


  • Customising your transfer tape

    Utilising the latest converting technologies, we can customise your adhesive transfer tape to create non-standard roll widths and lengths, or convenient and easy to handle components. Customising your tape offers a number of benefits, including cost savings and enhanced product design. Whatever your needs, we have the experience and capabilities to provide a complete solution, from design and prototyping to full production and automated assembly.
