Adhesive Transfer tape

Adhesive Transfer tape

  • Overview
  • Products
  • Case Studies
  • Capabilities
  • Media

  • About adhesive transfer tape

    An adhesive transfer tape is a pressure sensitive adhesive with no carrier, directly coated onto a release liner. These tapes very quickly bond two surfaces and can be easily applied by hand, with a dispenser or using automated pick and place technology. They are designed to increase manufacturing efficiency by replacing traditional bonding and fastening materials, offering a reliable bonding solution.

    Adhesive transfer tapes are especially suitable where a thin and invisible bond is required and are ideal for bonding lightweight materials like paper, cloth or plastic. They are available in a variety of thicknesses and adhesive formulations and will attach a wide range of similar and dissimilar materials. Repositionable transfer tapes are also available and can be removed and reused numerous times without leaving any adhesive residue.

    We can easily combine transfer tapes with other materials,  such as laminating to foams. They are easily die-cut into convenient shapes and sizes; offering a variety of options to meet your individual needs.

    We offer an extensive range of transfer tapes from World leading manufacturers. Click on the products tab for more information.

  • Search adhesive transfer tapes

    Browse through our range of adhesive transfer tapes below for more detailed information and product data sheets. If you would like to ask us a question about any of these products, simply click on “add to wish list” and the product details can be added to a contact form once you’re ready to get in touch. You can also send these details to yourself or a colleague.


    Select or remove columns to display
    Select or remove columns to display
    • Adhesive
    • Carrier
    • Colour
    • Thickness (mm)
    • Min. temp (ËšC)
    • Max. long temp (ËšC)
    • Max. short temp (ËšC)
    • Chem resist
    • UV resist
    • Bond to metal
    • Bond to HSE plastic
    • Bond to LSE plastic
    • Bond to foam, felt, mesh
    • Max width (cm)
    • Max length (m)
    • Manufacturer / SOS
    • D/S or S/S
    • Sterilisation method
    Filter By
    Filter By

    • Thickness range (mm)

    • Temp. range (ËšC)

    • Adhesive

    • Carrier

    • Colour

    • Chem resist

    • UV resist

    • Bond to metal

    • Bond to HSE plastic

    • Bond to LSE plastic

    • Bond to foam, felt, mesh

    • Max width (cm)

    • Max length (m)

    • Manufacturer / SOS

    • D/S or S/S

    • Sterilisation method

    Reset Filters

    Any data provided relates to values typically generated when measuring these materials, and is offered as a guide to material selection. However it is not guaranteed and the user is responsible for evaluating the suitability of a product for the application it is intended for. Some test methods may vary, please refer to data sheet or call for assistance.

    Title Adhesive Bond to foam, felt, mesh Bond to HSE plastic Bond to LSE plastic Bond to metal Carrier Chem resist Colour D/S or S/S Manufacturer / SOS Max length (m) Max. long temp (ËšC) Max. short temp (ËšC) Max width (cm) Min. temp (ËšC) Sterilisation method Thickness (mm) UV resist
    3Mâ„¢ 9882 3Mâ„¢ 9882 3 Acrylic Filled acrylic polymer 3 Grey 3Mâ„¢ No data -35 0.05 4
    Vanciveâ„¢ MED 2190H Vanciveâ„¢ MED 2190H 3 Hydrocolloid None No data Transparent Double sided Vanciveâ„¢ No data No data No data No data Gamma 0.51 No data
    Vanciveâ„¢ MED 2191H Vanciveâ„¢ MED 2191H 3 Hydrocolloid None No data Transparent Double sided Vanciveâ„¢ No data No data No data No data Gamma 1 No data
    Vanciveâ„¢ MED 2195H Vanciveâ„¢ MED 2195H 3 Hydrocolloid None No data Transparent Double sided Vanciveâ„¢ No data No data No data No data Gamma 0.51 No data
    Vanciveâ„¢ MED 2198H Vanciveâ„¢ MED 2198H 3 Hydrocolloid None No data Transparent Vanciveâ„¢ No data No data 0.41 No data
    3Mâ„¢ 9703 3Mâ„¢ 9703 2 Acrylic No data 2 2 3 None 3 Clear 3Mâ„¢ No data -40 0.05 4
    Laird Tgonâ„¢ 805 Laird Tgonâ„¢ 805 3 None Flexible graphite Pewter Laird -240 0.13
    3Mâ„¢ 8805 3Mâ„¢ 8805 1 Acrylic Filled acrylic polymer No data White 3Mâ„¢ No data No data 0.13 No data
    3Mâ„¢ 9885 3Mâ„¢ 9885 3 Acrylic Filled acrylic polymer 3 Grey 3Mâ„¢ No data -35 0.13 4
    3M™ 5516 3M™ 5516 1 None Filled silicone polymer‎ Grey 3M™ No data 1
    3Mâ„¢ 8810 3Mâ„¢ 8810 1 Acrylic Filled acrylic polymer No data White 3Mâ„¢ No data No data 0.25 No data
    3Mâ„¢ 8815 3Mâ„¢ 8815 2 Acrylic Filled acrylic polymer No data White 3Mâ„¢ No data No data 0.38 No data
    Vanciveâ„¢ MED 2171H Vanciveâ„¢ MED 2171H 3 Hydrocolloid None No data Transparent Double sided Vanciveâ„¢ No data No data No data No data Gamma 0.3 No data
    3Mâ„¢ 98010LVC 3Mâ„¢ 98010LVC 2 Acrylic 4 4 4 4 None 3 Clear 3Mâ„¢ 121 -30 0.1 3
    3Mâ„¢ 99015LVC 3Mâ„¢ 99015LVC 2 Acrylic 4 4 4 4 Tissue 3 Clear 3Mâ„¢ 182 -30 0.15 3
    3Mâ„¢ 1524A 3Mâ„¢ 1524A 3 Acrylic None Transparent Double sided 3Mâ„¢ 366 122 No data EtO, Gamma & Steam 0.06
    Vanciveâ„¢ MED 21010H Vanciveâ„¢ MED 21010H 3 Hydrocolloid None No data Double sided Vanciveâ„¢ 365 152.4 No data Gamma 0.6
    Vanciveâ„¢ MED 21009H Vanciveâ„¢ MED 21009H 2 Hydrocolloid None No data Double sided Vanciveâ„¢ 365 152.4 No data Gamma 0.3
    Vanciveâ„¢ MED 2159H Vanciveâ„¢ MED 2159H 3 Hydrocolloid None No data Transparent Double sided Vanciveâ„¢ No data 152.4 No data Gamma 1.2 No data
    Vanciveâ„¢ MED 2196H Vanciveâ„¢ MED 2196H 3 Hydrocolloid None No data Transparent Double sided Vanciveâ„¢ No data 152.4 No data Gamma 2.4 No data
    Avery Dennisonâ„¢ MED 2120U Avery Dennisonâ„¢ MED 2120U 3 Acrylic None No data Transparent Double sided Avery Dennison Medical No data 152.4 No data EtO & Gamma 0.06 No data
    Avery Dennisonâ„¢ MED 2121U Avery Dennisonâ„¢ MED 2121U 3 Acrylic None No data Transparent Double sided Avery Dennison Medical No data 152.4 No data EtO & Gamma 0.04 No data
    Avery Dennisonâ„¢ MED 2123R Avery Dennisonâ„¢ MED 2123R 3 Synthetic rubber None No data Transparent Double sided Avery Dennison Medical No data 152.4 No data EtO & Gamma 0.04 No data
    Solventumâ„¢ (formerly 3Mâ„¢) 4075 Solventumâ„¢ (formerly 3Mâ„¢) 4075 Acrylic None Transparent Double sided 3Mâ„¢ No data EtO 0.07
    3Mâ„¢ 9713 3Mâ„¢ 9713 3 Acrylic No data No data No data No data None No data No data 3Mâ„¢ 70 No data 0.09 No data
    3Mâ„¢ 927 3Mâ„¢ 927 1 Acrylic 3 5 4 5 None 3 Clear 3Mâ„¢ 82 -30 0.05 4
    3Mâ„¢ 950 3Mâ„¢ 950 1 Acrylic 5 5 5 4 None 3 Clear 3Mâ„¢ 82 -30 0.127 4
    3Mâ„¢ 966 3Mâ„¢ 966 2 Acrylic 1 4 1 5 None 5 Clear 3Mâ„¢ 149 -40 0.06 5
    3Mâ„¢ 8171 3Mâ„¢ 8171 3 Acrylic 2 5 2 5 None 5 Optically clear 3Mâ„¢ 85 -40 0.025 5
    3Mâ„¢ 8172 3Mâ„¢ 8172 3 Acrylic 2 5 2 5 None 5 Optically clear 3Mâ„¢ 85 -40 0.05 5
    3Mâ„¢ F-9465PC 3Mâ„¢ F-9465PC 2 Acrylic 2 4 1 5 None 2 Clear 3Mâ„¢ 74 -30 0.13 4
    3Mâ„¢ 9482PC 3Mâ„¢ 9482PC 1 Acrylic 5 5 5 5 None 4 Clear 3Mâ„¢ 150 -40 0.05 4
    3Mâ„¢ 9485 3Mâ„¢ 9485 1 Acrylic 5 5 5 5 None 4 Clear 3Mâ„¢ 149 -40 0.127 4
    3Mâ„¢ 9605 3Mâ„¢ 9605 1 Acrylic 3 4 3 4 None 3 Clear 3Mâ„¢ 120 -30 0.05 4
    3Mâ„¢ 9626 3Mâ„¢ 9626 2 Acrylic 5 5 5 5 None 4 Clear 3Mâ„¢ 93 -40 0.05 4
    3Mâ„¢ 9627 3Mâ„¢ 9627 2 Acrylic 5 5 5 5 None 4 Clear 3Mâ„¢ 93 -40 0.13 4
    3Mâ„¢ 465 3Mâ„¢ 465 3 Acrylic 2 3 3 3 None 3 Clear 3Mâ„¢ 82 -30 0.05 4
    3M 467MP 3M 467MP 1 Acrylic 1 5 1 5 None 4 Clear 3Mâ„¢ 149 -30 0.06 5
    3Mâ„¢ 468MP 3Mâ„¢ 468MP 1 Acrylic 1 5 1 5 None 4 Clear 3Mâ„¢ 149 -30 0.13 5
    3Mâ„¢ 920XL 3Mâ„¢ 920XL 2 Acrylic 3 4 3 5 None 3 Clear 3Mâ„¢ 80 -30 0.025 4
    3Mâ„¢ 9471LE 3Mâ„¢ 9471LE 1 Acrylic 1 5 5 5 None 4 Clear 3Mâ„¢ 93 -40 0.058 4
    3Mâ„¢ 9472LE 3Mâ„¢ 9472LE 2 Acrylic 1 5 5 5 None 4 Clear 3Mâ„¢ 93 -40 0.132 4
    3Mâ„¢ F9460PC VHBâ„¢ 3Mâ„¢ F9460PC VHBâ„¢ 1 Acrylic 1 4 1 5 None 5 Clear 3Mâ„¢ 149 -30 0.05 5
    3Mâ„¢ F9469PC VHBâ„¢ 3Mâ„¢ F9469PC VHBâ„¢ 1 Acrylic 1 4 1 5 None 5 Clear 3Mâ„¢ 149 -30 0.13 5
    3Mâ„¢ F9473PC VHBâ„¢ 3Mâ„¢ F9473PC VHBâ„¢ 1 Acrylic 1 4 1 5 None 5 Clear 3Mâ„¢ 149 -30 0.26 5
    3Mâ„¢ 1504XL 3Mâ„¢ 1504XL 3 Synthetic rubber None No data Translucent Double sided 3Mâ„¢ 549 No data 15 No data EtO & Gamma 0.11 No data
    Adhesives Research 7396 Adhesives Research 7396 3 Acrylic None Translucent Double sided Adhesives Research No data Gamma 0.12
    Adhesives Research 8026 Adhesives Research 8026 3 Silicone None No data No data Double sided Adhesives Research No data No data No data -73 No data 0.025 No data

  • Adhesive transfer tape in action

    Read through our case studies to find relevant, real-life examples of the powerful problem solving capabilities of a roll of tape! Browse all case studies to learn more about custom die-cut components and our tape converting capabilities.


  • Customising your transfer tape

    Utilising the latest converting technologies, we can customise your adhesive transfer tape to create non-standard roll widths and lengths, or convenient and easy to handle components. Customising your tape offers a number of benefits, including cost savings and enhanced product design. Whatever your needs, we have the experience and capabilities to provide a complete solution, from design and prototyping to full production and automated assembly.

    • Die-cutting
      Die-cutting
    • Slitting
      Slitting
    • Laser cutting
      Laser cutting
    • Guillotining
      Guillotining
    • Laminating
      Laminating
    • Bespoke presentations
      Bespoke presentations
    • X/Y axis plotter
      X/Y axis plotter
    • Rapid prototyping
      Rapid prototyping
    • Clean room manufacturing
      Clean room manufacturing
    • Automation solutions
      Automation solutions
    • R&D
      R&D
    • Computer Aided Design
      Computer Aided Design
    • Contract converting
      Contract converting
    • Part tolerances
      Part tolerances

  • Learn more about transfer tape

    To learn more about adhesive transfer tape and its uses, browse through our range of interesting and relevant videos, news and other media.
