3M™ 8904-0.25 thermally conductive interface tape is designed with a soft acrylic adhesive and multiple thickness options to allow excellent wet-out and conformability to many surfaces. It has good adhesion performance to many substrate types and has excellent dielectric performance.
8904-0.25 is filled with thermally conductive ceramic particles and flame retardant fillers. It is available in non-standard slit rolls, sheets or custom shapes.
For more information, please contact us.
Adhesive | Acrylic |
Carrier | PET |
Colour | White |
Thickness (mm) | 0.25 |
Max. long temp (˚C) | No data |
Chem resist | No data |
UV resist | No data |
Stock status | 3 |
Min. temp (˚C) | No data |
Max. long temp (˚C) | No data |
Max. short temp (˚C) | 80 |
Shore Hardness (00) | N/A |
Manufacturer / SOS | 3M™ |
Thermal conductivity (W/m-K) | >1.5 |
Dielectric strength (kV/mm) | 15 |
Thermal impedance (˚C-cm²/W) | 8.74 |
