3M™ 9793R is a transparent single coated polyolefin diagnostic tape. It has a clear polyolefin film coated on one side with a 3M select diagnostic acrylate adhesive.
This tape offers bioassay compatible adhesive with non-clouding features when exposed to moisture. It is low auto-fluorescing and can be sterilised by EtO.
9793R tape is used for microplate seals for PCR, ELISA and other bioanalytical applications. It is available in non-standard slit rolls, sheets and custom shapes.
Download: 9793r-polyolefin-diagnostic
Adhesive |
Acrylic |
Carrier |
PP |
Colour |
Transparent |
Thickness (mm) |
0.08 |
Min. temp (˚C) |
-70 |
Max. short temp (˚C) |
100 |
Manufacturer / SOS |
3M™ |
Elongation (%) |
186 |
Adhesion to steel (N/cm) |
2.8 |
Tensile strength (N/cm²) |
No data |
D/S or S/S |
Single sided |
Breathable |
No |
Conformability |
Medium |
Fluid resist backing |
Yes |
Hypoallergenic |
No |
Sterilisation method |
EtO |
MVTR (gms/m2 /24 hrs) |
No data |
Max width (cm) |
122 |
Max length (m) |
457 |
