3M™ 9890 thermally conductive adhesive transfer tape is no longer available. Please consider using 3M™ 8926 instead.
Contact us for availability of remaining stock and replacement suggestions. Please ensure proper trials are conducted to confirm suitability of the suggested replacement.
Adhesive | Acrylic |
Carrier | Filled acrylic polymer |
Colour | Grey |
Thickness (mm) | 0.25 |
Max. long temp (˚C) | No data |
Chem resist | 3 |
UV resist | 4 |
Min. temp (˚C) | -35 |
Max. long temp (˚C) | No data |
Max. short temp (˚C) | 100 |
Shore Hardness (00) | N/A |
Manufacturer / SOS | 3M™ |
Thermal conductivity (W/m-K) | 0.6 |
Dielectric strength (kV/mm) | 29 |
Thermal impedance (˚C-cm²/W) | 3.2 |
