AccuPlace 4065 is a legacy machine. As such, it is no longer sold, however, we still provide technical support to customers who already have this machine. If you are looking to purchase AccuPlace 4065 or upgrade your existing automation equipment, we recommend you consider AccuPlace 650 instead.
AccuPlace 4065 assembles any self-adhesive component no larger than 1016mm x 165mm. The machine is compact and has various options and features to allow for component’s specific requirements. It has full serial control communications and an intuitive interface.
AccuPlace 4065 can be mounted in any direction.
Download: AccuPlace_4065_Parafix
Accuracy (mm) |
±0.05 |
Max. liner width (mm) |
165 |
Max. component length (mm) |
101.6 |
Max. component thickness (mm) |
6 |
Electrical interface |
2 outputs: ready & clear; 1 input: cycle |
Stroke (mm) |
127, 203 |
Mounting orientation |
Any |
