Overview for Arlon A3020-X004-3.3 self amalgamating tape

Arlon A3020-X004-3.3 is a 25mm wide, fiberglass reinforced, rectangular self amalgamating tape. This product contains sinusoidal fiberglass fabric that gives a controlled elongation, increased tear resistance and tensile strength. It has a minimum elongation before fracture of 25%. The reinforcement has excellent mechanical characteristics while allowing the tape to conform to irregular shapes.

For more information, please contact us.

Arlon A3020-X004-3.3 self amalgamating tape

Product features for Arlon A3020-X004-3.3 self amalgamating tape

Adhesive

None

Carrier

Silicone rubber

Colour

Grey

Thickness (mm)

0.5

Max. short temp (˚C)

260

Manufacturer / SOS

Arlon

Elongation (%)

25

Adhesion to steel (N/cm)

N/A

Tensile strength (N/cm²)

No data

Insulation resistance (MΩ)

No data

Electrostatic corrosion

No data
