Porex membrane disc PMV15I

Porex membrane disc PMV15I

Overview for Porex membrane disc PMV15I

Porex PMV15I is a 0.37mm thick venting disc with 3M 9086 adhesive. It has IP ratings of 64, 67 and 68 and is compliant with RoHS, WEEE and REACH.

PMV15 material can be supplied, with or without adhesive, in custom disc sizes, other shapes, sheets and rolls.

For more information, please contact us.

Download: porex-pmv15i-data-sheet-parafix

Download:

Add to wish list View Data Sheet
Porex membrane disc PMV15I
Add to Wishlist

Product features for Porex membrane disc PMV15I



Adhesive

Modified acrylic

Carrier

PTFE

Colour

White

Thickness (mm)

0.37

Min. temp (˚C)

-40

Manufacturer / SOS

Porex

Max. temp (˚C)

85

Nominal gurley (seconds)

No data

Airflow rates (l/hr @70mb)

≥17.4

Water intrusion pressure (mb)

≥ 265

IP rating

IP67

Filtration efficiency >99.99% (µ)

0.4

Size

10×7
