Vancive™ MED 5674U

Overview for Vancive™ MED 5674U

Vancive™ MED 5674U is a single coated, soft, conformable, thin polyethylene foam with a solventless acrylic adhesive.

This product’s high tack and level of adhesion provide for an aggressive bond to the skin, even under stress conditions. MED 5674U is moisture resistant and can be sterilised by EtO and gamma. It is designed for mounting electrodes, grounding pads and other devices for sustained periods.

5674U is available in non-standard slit rolls, sheets and custom die-cuts.

Download: vancive-med-5674u-foam-tape-parafix.v1

Download:

Add to wish list View Data Sheet

Add to Wishlist

Product features for Vancive™ MED 5674U

Adhesive	Acrylic
Carrier	PE foam
Colour	White
Thickness (mm)	1.07
Min. temp (˚C)	No data
Max. short temp (˚C)	No data
Density (kg/m³)	No data
Shore Hardness (00)	No data
Compression set % max - 23˚C	No data
Compression Deflection 25% (kPa)	No data
Manufacturer / SOS	Vancive™
Elongation (%)	450
Adhesion to steel (N/cm)	5.8
Tensile strength (N/cm²)	No data
D/S or S/S	Single sided
Breathable	No data
Conformability	No data
Fluid resist backing	No data
Hypoallergenic	No
Sterilisation method	EtO & Gamma
MVTR (gms/m2 /24 hrs)	No data
Max width (cm)	No data
Max length (m)	No data
