3M™ AL36NC is a PET laminated aluminium foil shielding tape, coated on one side with an acrylic adhesive. The PET-laminated to aluminium foil backing insulates the shield from neighbouring circuits. It is typically used for applications requiring non-electrical conductivity from the application substrate to the backing and needing insulation on top of the foil backing.
AL36NC tape has a UL510 flame rating and is available in non-standard slit rolls, sheets and custom shapes.
For more information, please contact us.
Adhesive | Acrylic |
Carrier | Polyester / aluminium foil |
Colour | Silver |
Thickness (mm) | 0.07 |
Min. temp (˚C) | No data |
Max. short temp (˚C) | No data |
Manufacturer / SOS | 3M™ |
Adhesion to steel (N/cm) | 500 |
Tensile strength (N/cm²) | 6.5 |
Shielding Effectiveness @GHz(dB) | 65 |
Electrical resistance (Ω) | No data |
