Overview for 3M™ PT1100

3M™ PT1100 is an acrylic foam tape with outstanding adhesion to many automotive paints and MSE (medium surface energy) plastics. It has two adhesives: liner-side adhesive is designed for traditional, LSE and mar-resistant paints, while the non-liner side has excellent adhesion to metal and plastic parts. This automotive tape is commonly used in attaching body side and door edge mouldings, interior trim panels and wheel flares.

3M™ PT1100 tape is available in non-standard slit rolls, sheets and custom shapes.

Download: 3m-vhb-PT1100-Parafix

Download:

3M™ PT1100

Product features for 3M™ PT1100

Adhesive

Acrylic

Carrier

Foamed acrylic adhesive

Colour

Black

Thickness (mm)

1.2

Max. long temp (˚C)

90

Chem resist

5

UV resist

5

Bond to foam, felt, mesh

No data

Min. temp (˚C)

-40

Max. long temp (˚C)

90

Max. short temp (˚C)

120

Bond to metal

5

Bond to HSE plastic

5

Density (kg/m³)

545

Shore Hardness (00)

No data

Compression set % max - 23˚C

No data

Compression Deflection 25% (kPa)

No data

Manufacturer / SOS

3M™
