Vanciveā„¢ MED 5684U

Vanciveā„¢ MED 5684U

Overview for Vanciveā„¢ MED 5684U

Vancive MED 5684U is a 1.07mm thick polyethylene foam, coating on one side with an acrylic adhesive. It is moisture resistant and can be sterilised by Gamma and EtO.

Vancive MED 5684U is used for mounting electrodes and grounding pads for sustained periods.

This product is available in non-standard slit rolls, sheets and custom shapes.

Download: vancive-med-5684u-parafix

Download:

Add to wish list View Data Sheet
Vanciveā„¢ MED 5684U
Add to Wishlist

Product features for Vanciveā„¢ MED 5684U

Adhesive

Acrylic
Carrier

PE foam
Colour

Pink
Thickness (mm)

1.07
Min. temp (ĖšC)

No data
Max. short temp (ĖšC)

No data
Density (kg/mĀ³)

No data
Shore Hardness (00)

No data
Compression set % max - 23ĖšC

No data
Compression Deflection 25% (kPa)

No data
Manufacturer / SOS

Vanciveā„¢
Elongation (%)

450
Adhesion to steel (N/cm)

5.8
Tensile strength (N/cmĀ²)

No data
D/S or S/S

Single sided
Breathable

No data
Conformability

Very high
Fluid resist backing

No
Hypoallergenic

No
Sterilisation method

EtO & Gamma
MVTR (gms/m2 /24 hrs)

No data
Max width (cm)

152.4
Max length (m)

365
