Vancive™ MED 5688A

Overview for Vancive™ MED 5688A

Vancive MED 5688A is a 0.8mm thick polyethylene foam, coated on one side with an acrylic adhesive. It is resistant to moisture and creasing and can be sterilised by Gamma and EtO.

Vancive MED 5688A is used for ostomy applications, mounting electrodes, grounding pads and other devices for sustained periods.

This product is available in non-standard slit rolls, sheets and custom shapes.

Download: vancive-med-5688a-parafix

Download:

Add to wish list View Data Sheet

Add to Wishlist

Product features for Vancive™ MED 5688A

Adhesive	Acrylic
Carrier	PE foam
Colour	White
Thickness (mm)	0.8
Min. temp (˚C)	No data
Max. short temp (˚C)	No data
Density (kg/m³)	No data
Shore Hardness (00)	No data
Compression set % max - 23˚C	No data
Compression Deflection 25% (kPa)	No data
Manufacturer / SOS	Vancive™
Elongation (%)	400
Adhesion to steel (N/cm)	6.4
Tensile strength (N/cm²)	No data
D/S or S/S	Single sided
Breathable	No data
Conformability	Very high
Fluid resist backing	No
Hypoallergenic	No
Sterilisation method	EtO & Gamma
MVTR (gms/m2 /24 hrs)	No data
Max width (cm)	152.4
Max length (m)	365
