3M™ 1350BK

3M™ 1350BK

Overview for 3M™ 1350BK

3M™ 1350BK tape is a UL510 flame retardant polyester insulation tape coated on one side with an acrylic adhesive. It is especially suited for applications such as wrapping coils, capacitors, wire harnesses, transformers, shaded pole motors and fractional horsepower motors.

Electrically insulating 1350BK tape is available in non-standard slit rolls, sheets or custom shapes.

For more information, please contact us.

3M™ 1350BK

Product features for 3M™ 1350BK

Adhesive

Acrylic

Carrier

Polyester

Colour

Black

Thickness (mm)

0.06

Max. short temp (˚C)

130

Manufacturer / SOS

3M™

Elongation (%)

75

Adhesion to steel (N/cm)

3.3

Tensile strength (N/cm²)

44

Insulation resistance (MΩ)

>1×10⁶

Electrostatic corrosion

1
