3M™ 1350BK tape is a UL510 flame retardant polyester insulation tape coated on one side with an acrylic adhesive. It is especially suited for applications such as wrapping coils, capacitors, wire harnesses, transformers, shaded pole motors and fractional horsepower motors.
Electrically insulating 1350BK tape is available in non-standard slit rolls, sheets or custom shapes.
For more information, please contact us.
Download: 3m-1350f-1-black-data-sheet-parafix
Adhesive |
Acrylic |
Carrier |
Polyester |
Colour |
Black |
Thickness (mm) |
0.06 |
Max. short temp (˚C) |
130 |
Manufacturer / SOS |
3M™ |
Elongation (%) |
75 |
Adhesion to steel (N/cm) |
3.3 |
Tensile strength (N/cm²) |
44 |
Insulation resistance (MΩ) |
>1×10⁶ |
Electrostatic corrosion |
1 |
