3M™ 1350Y

Overview for 3M™ 1350Y

3M™ 1350 tape is a polyester insulation tape coated with an acrylic adhesive on one side. It is especially suited for applications such as wrapping coils, capacitors, wire harnesses, transformers, shaded pole motors and fractional horsepower motors.

Electrically insulating 1350Y tape is available in non-standard slit rolls, sheets or custom shapes.

For more information, please contact us.

Download: 1350f-1-yellow-data-sheet-parafix

Download:

Add to wish list View Data Sheet

Add to Wishlist

Product features for 3M™ 1350Y

Adhesive	Acrylic
Carrier	Polyester
Colour	Yellow
Thickness (mm)	0.06
Max. short temp (˚C)	130
D/S or S/S	Single sided
Manufacturer / SOS	3M™
Elongation (%)	75
Adhesion to steel (N/cm)	3.3
Tensile strength (N/cm²)	45
Insulation resistance (MΩ)	>1×10⁶
Electrostatic corrosion	1
