Overview for 3M™ 56 polyester film electrical tape

3M™ 56 tape is a polyester film insulating tape coated on one side with a rubber adhesive. It is especially suited for use as layer insulation and coil cover in 130°C applications.

Electrically insulating 56 tape is available in non-standard slit rolls, sheets or custom shapes.

For more information, please contact us.

Download: 3m-electrical-tape-56-parafix

Download:

Add to wish list View Data Sheet
3M™ 56 polyester film electrical tape
Add to Wishlist

Product features for 3M™ 56 polyester film electrical tape

Adhesive

Rubber
Carrier

Polyester
Colour

Yellow
Thickness (mm)

0.06
Max. short temp (˚C)

130
Manufacturer / SOS

3M™
Elongation (%)

100
Adhesion to steel (N/cm)

5.5
Tensile strength (N/cm²)

44
Insulation resistance (MΩ)

>1×10⁶
Electrostatic corrosion

1
