3M™ 57 tape is a polyester insulating film tape coated on one side with a rubber thermosetting adhesive. It is suited for use as a coil cover; layer insulation and capacitor wrap where higher electrical strength is desirable.
57 polyester film electrical tape is available in non-standard slit rolls, sheets and custom shapes.
For more information, please contact us.
Download: 3m-electrical-tape-57-parafix
Adhesive | Rubber |
Carrier | Polyester |
Colour | Yellow |
Thickness (mm) | 0.08 |
Max. short temp (˚C) | 130 |
Manufacturer / SOS | 3M™ |
Elongation (%) | 110 |
Adhesion to steel (N/cm) | 6.5 |
Tensile strength (N/cm²) | 88 |
Insulation resistance (MΩ) | >1×10⁶ |
Electrostatic corrosion | 1 |
