3M™ 58 polyester film electrical tape

3M™ 58 polyester film electrical tape

Overview for 3M™ 58 polyester film electrical tape

3M™ 58 tape is a polyester insulating tape coated on one side with a rubber adhesive. It is suited for use as a coil cover; layer insulation and capacitor wrap where higher electrical strength is desirable.

Electrically insulating 58 tape is available in non-standard slit rolls, sheets and custom shapes.

For more information, please contact us.

Download: 3m-electrical-tape-58-parafix

Download:

3M™ 58 polyester film electrical tape

Product features for 3M™ 58 polyester film electrical tape

Adhesive

Rubber

Carrier

Polyester

Colour

Clear

Thickness (mm)

0.08

Max. short temp (˚C)

130

Manufacturer / SOS

3M™

Elongation (%)

110

Adhesion to steel (N/cm)

6.5

Tensile strength (N/cm²)

88

Insulation resistance (MΩ)

>1×10⁶

Electrostatic corrosion

1
