3M™ GPH-060GF

3M™ GPH-060GF

Overview for 3M™ GPH-060GF

3M™ GPH-060GF is a general purpose, high temperature VHB tape offering a good balance of high temperature, peel and shear performance. It is a conformable and soft acrylic foam with a high initial tack and good sealing properties.

This product is ideal for applications requiring multi-material bonding, with a high or medium surface energy, as it will bond to a variety of substrates, including metals and plastics.

Its temperature performance enables bonding of materials in applications with high operating temperatures such as prior to processing in a powder coating line. It is commonly used in applications in metal working, signage, appliances and specialty vehicles.

GPH-060GF is available in other thicknesses and in non-standard slit rolls, sheets and custom shapes.

For more information, please contact us.

Download: 3m-gph-060gf-vhb-parafix

Download:

3M™ GPH-060GF

Product features for 3M™ GPH-060GF

Adhesive

Acrylic

Carrier

Foamed acrylic adhesive

Colour

Grey

Thickness (mm)

0.6

Max. long temp (˚C)

150

Chem resist

No data

UV resist

No data

Bond to foam, felt, mesh

No data

Min. temp (˚C)

No data

Max. long temp (˚C)

150

Max. short temp (˚C)

230

Bond to metal

No data

Bond to HSE plastic

No data

Bond to LSE plastic

No data

Density (kg/m³)

710

Shore Hardness (00)

No data

Compression set % max - 23˚C

No data

Compression Deflection 25% (kPa)

No data

Manufacturer / SOS

3M™
