3M™ VHB™ 4614F

3M™ VHB™ 4614F

Overview for 3M™ VHB™ 4614F

3M™ 4614F is a 0.8mm clear high bond acrylic VHB™ foam tape. This product is a high performance acrylic foam product which possesses a good balance between shear peel and high tack adhesion. It has been designed to be suitable for a range of bonding applications which require a level of adhesion higher than standard double coated foam tapes, but perhaps lower than higher performance 3M™ VHB™ tapes.

Typical applications include bonding clear materials such as commercial signage and point of purchase materials. 4614F VHB™ tape is available in non-standard slit rolls, sheets and custom shapes.

For more information, please contact us.

Download: 3m-vhb-4614f-tape-parafix.v1

Download:

3M™ VHB™ 4614F

Product features for 3M™ VHB™ 4614F

Adhesive

Acrylic

Carrier

Foamed acrylic adhesive

Colour

Clear

Thickness (mm)

0.8

Max. long temp (˚C)

90

Chem resist

5

UV resist

5

Bond to foam, felt, mesh

No data

Min. temp (˚C)

-30

Max. long temp (˚C)

90

Max. short temp (˚C)

150

Bond to metal

No data

Bond to HSE plastic

No data

Bond to LSE plastic

No data

Density (kg/m³)

960

Shore Hardness (00)

No data

Compression set % max - 23˚C

No data

Compression Deflection 25% (kPa)

No data

Manufacturer / SOS

3M™
