Laird Tpcm™ 5810 is a high-performance thermal phase change material (PCM) designed to meet the thermal reliability and price requirements of high-end thermal applications. It is a non-reinforced film with a phase change softening temperature of 50°C. At temperatures above its transition temperature, Tpcm™ 5810 begins to soften and flow, filling the microscopic irregularities of the components it comes into contact with. The result is an interface with minimal thermal contact resistance. Due to the gradual change in viscosity (softening), it minimises migration (pump-out).
This product is inherently tacky, flexible and exceptionally easy-to-use. Tpcm™ 5810 is reliable, offers low total thermal resistance and meets all environmental requirements including RoHS. Common applications include microprocessors, chipsets, graphic processing chips and custom ASICS.
Tpcm™ 5810 is available in custom roll widths, sheets or die-cut shapes. For more information, please contact us.
Download: laird-tpcm-580-series-tpcm-5810-parafix
Adhesive |
None |
Carrier |
Non-reinforced film |
Colour |
Grey |
Thickness (mm) |
0.25 |
Min. temp (˚C) |
-40 |
Max. short temp (˚C) |
125 |
Manufacturer / SOS |
Laird |
Thermal conductivity (W/m-K) |
3.8 |
Dielectric strength (kV/mm) |
No data |
Thermal impedance (˚C-cm²/W) |
0.013 |
