3M™ 1182

Overview for 3M™ 1182

3M™ 1182 is a double sided EMI shielding tape with a dead soft copper foil carrier, coated on both sides with a conductive acrylic adhesive. The conductive particles in the adhesive provides low contact resistance between substrates and the backing to drain static charge.

1182 tape makes an excellent conductive gasket and is typically used to bond two surfaces together, both electrically and physically.

1182 tape has a UL 510 flame rating and is available in non-standard slit rollls, sheets and custom shapes.

For more information, please contact us.

3M™ 1182

Product features for 3M™ 1182

Adhesive

Acrylic

Carrier

Copper foil

Colour

Copper

Thickness (mm)

0.09

Max. long temp (˚C)

No data

Chem resist

No data

UV resist

No data

Bond to foam, felt, mesh

No data

Min. temp (˚C)

No data

Max. long temp (˚C)

No data

Max. short temp (˚C)

No data

Bond to metal

No data

Bond to HSE plastic

No data

Bond to LSE plastic

No data

Manufacturer / SOS

3M™

Adhesion to steel (N/cm)

3.8

Tensile strength (N/cm²)

44

Shielding Effectiveness @GHz(dB)

85

Electrical resistance (Ω)

0.01
