3M Super 20 epoxy film electrical tape is an insulation tape coated on one side with an acrylic adhesive. It is suggested for use in wrapping relays, coils, transformers, bobbin-wound subfractional horsepower shaded-pole motors and stick-wound coils. It can also be used for holding in fractional horsepower motors, arbor-wound coils and wire harnesses.
Electrically insulating 3M Super 20 tape is available in non-standard slit rolls, sheets and custom shapes.
For more information, please contact us.
Download: 3m-electrical-tape-20-parafix
Adhesive | Acrylic |
Carrier | Epoxy |
Colour | Cream |
Thickness (mm) | 0.13 |
Max. short temp (˚C) | 155 |
Manufacturer / SOS | 3M™ |
Elongation (%) | 120 |
Adhesion to steel (N/cm) | 3.3 |
Tensile strength (N/cm²) | 79 |
Insulation resistance (MΩ) | >1×10⁶ |
Electrostatic corrosion | 1 |
