Overview for 3M 27 glass cloth electrical tape

3M 27 glass cloth electrical tape is coated on one side with a rubber thermosetting adhesive. It is designed to operate in 600-volt dry applications requiring high mechanical strength and resistance to high temperatures.

The glass cloth is specially treated and prepared to provide corrosion free protection. It has a high tensile strength and will not shrink, rot or burn.

Electrically insulating 3M 27 tape is available in non-standard slit rolls, sheets and custom shapes.

For more information, please contact us.

Download: 3m-electrical-tape-27-parafix

Download:

3M 27 glass cloth electrical tape

Product features for 3M 27 glass cloth electrical tape

Adhesive

Rubber

Carrier

Cloth

Colour

White

Thickness (mm)

0.18

Max. short temp (˚C)

130

Manufacturer / SOS

3M™

Elongation (%)

5

Adhesion to steel (N/cm)

3.3

Tensile strength (N/cm²)

252

Insulation resistance (MΩ)

2.5/10²

Electrostatic corrosion

0.9
