3M™ 5414 tape is a water soluble wave solder masking tape consisting of a PVA backing coated with a synthetic adhesive. It is a hazy transparent colour and is available in non-standard slit rolls, sheets and custom shapes.
Download: 3m-5414-tape-parafix
Adhesive |
Synthetic |
Carrier |
PVA |
Colour |
Transparent |
Thickness (mm) |
0.053 |
Min. temp (˚C) |
0 |
Max. short temp (˚C) |
240 |
Manufacturer / SOS |
3M™ |
Elongation (%) |
334 |
Adhesion to steel (N/cm) |
0.4 |
Tensile strength (N/cm²) |
11 |
